• Color-coordinated bumper fascias
• Color-coordinated body-side moldings
• Body-colored grille
• Halogen headlamps
• On-board headlamp aiming system
• High-gloss black pwr mirrors (RH convex)
• Complete solar-tinted flush-mount glass
• Manual RH sliding side door
• Black door handles

• 7-passenger seating
• Dual high-back reclining cloth front bucket seats w/headrests
• Second-row 2-passenger cloth bench seat w/adjustable headrests, folding seatback load floor
• Third-row 3-passenger cloth bench seat w/adjustable headrests, folding seatback load floor, utility hooks
• Enhanced seating group-inc: adjustable second/third row seat tracks w/rollers, first-row seat-back map pockets/grab handles, second-row seatback mounted cupholders
• Full-length color-coordinated carpeting
• Deluxe color-keyed steering wheel w/center horn button
• Locking tilt steering column
• Instrumentation-inc: fuel/temp gauges, tachometer
• Warning indicator lamps-inc: low fuel level, low oil pressure, charging system, high-beam indicator, low washer fluid
• Stalk controls-inc: turn signals, flash-to-pass, high-beam, wiper/washer
• Pwr front door windows w/driver-side one-touch down, pwr rear flip-out glass, illuminated switches
• Auto pwr locks w/illuminated front door switches, child-proof side-door lock
• "Securilock" passive anti-theft system
• Remote keyless entry-inc: illuminated entry system
• Speed control w/steering wheel mounted controls
• Forced-air ventilation/heater/defroster
• Manual front air conditioning
• Rear window defroster
• Electronic AM/FM stereo radio w/cassette-inc: digital clock, up/down scan, (4) speakers
• Antenna concealed in quarter glass
• Color-keyed front door trim panels w/padded armrest, cloth upper insert, carpet lower insert, map pocket, red reflector
• Black-framed windshield-mounted day/night mirror
• Molded full-length color-keyed cloth headliner
• Dual color-keyed cloth sun visors w/covered vanity mirrors
• Front dome/rear cargo lamps
• Light/visibility group-inc: floor/glovebox/2nd row reading/B-pillar lamps
• 2nd row LH side cargo net
• 12V pwr points located in front row & cargo area

• 4-wheel anti-lock braking system (ABS)
• Driver & front passenger second-generation airbags
• Driver/passenger 3-point passive safety belt w/height adjusters
• Rear 3-point shoulder/lap safety belts for outboard seating positions w/center lap belt for bench seat
• Second/third-row child safety seat anchors
• Fuel system inertia switch (located in RH jack stowage area)
• 5-mph bumpers
• Dual-note horn

3.8L (232) SPI V6 ENGINE

• (STD)

• Front Wheel Drive
• Tires - Front All-Season
• Tires - Rear All-Season
• Temporary Spare Tire
• Wheel Covers
• Steel Wheels
• Power Steering
• Front Disc/Rear Drum Brakes
• ABS
• Power Mirror(s)
• Third Passenger Door
• 3rd Row Seat
• Cloth Seats
• Bucket Seats
• 3rd Row Seat
• Adjustable Steering Wheel
• Power Windows
• Child Safety Locks
• Power Door Locks
• Engine Immobilizer
• Keyless Entry
• Power Door Locks
• Cruise Control
• A/C
• Rear Defrost
• AM/FM Stereo
• Cassette
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Rear Reading Lamps
• Power Outlet
• ABS
• Driver Air Bag
• Passenger Air Bag

• Vehicle
• EPA Classification: 2WD Minivans
• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 23
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 650
• Maximum Alternator Capacity (amps): 130
• Cooling System
• Total Cooling System Capacity (qts): 12.3
• Weight Information
• Base Curb Weight (lbs): 3890
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 100
• Suspension
• Suspension Type - Front: MacPherson Strut
• Suspension Type - Rear: Variable Rate Steel
• Suspension Type - Front (Cont.): w/Coil Springs
• Suspension Type - Rear (Cont.): Coil Springs
• Shock Absorber Diameter - Front (mm): 32.0
• Shock Absorber Diameter - Rear (mm): 30.2
• Stabilizer Bar Diameter - Front (in): 0.79
• Brakes
• Brake Type: Power
• Brake ABS System: 4 Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.1 x 1.02
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 9.84 x 2.17
• Tires
• Front Tire Order Code: T33
• Rear Tire Order Code: T33
• Front Tire Size: P205/70R15
• Rear Tire Size: P205/70R15
• Spare Tire Size: T135/90R15
• Wheels
• Front Wheel Size (in): 15.0 x 6.0
• Rear Wheel Size (in): 15.0 x 6.0
• Spare Wheel Size (in): 15.0 x 4.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power Rack & Pinion
• Steering Ratio (:1), Overall: 16.1
• Lock to Lock Turns (Steering): 2.96
• Turning Diameter - Curb to Curb (ft): 39.3
• Turning Diameter - Wall to Wall (ft): - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26.0
• Exterior Dimensions
• Wheelbase (in): 120.7
• Length, Overall (in): 200.9
• Width, Max w/o mirrors (in): 75.2
• Height, Overall (in): 65.6
• Track Width, Front (in): 64.7
• Track Width, Rear (in): 63.0
• Min Ground Clearance (in): 8.7
• Rear Door Opening Height (in): 40.5
• Rear Door Opening Width (in): 50.0
• Liftover Height (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 93.3
• Cargo Area Length @ Floor to Seat 2 (in): 59.6
• Cargo Area Length @ Floor to Seat 3 (in): 26.3
• Cargo Area Width @ Beltline (in): 69.6
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 46.2
• Cargo Volume to Seat 1 (ft³): 145.7
• Cargo Volume to Seat 2 (ft³): 76.3
• Cargo Volume to Seat 3 (ft³): 30.1
• Interior Dimensions
• Passenger Capacity: 7
• Passenger Volume (ft³): 144
• Front Head Room (in): 39.3
• Front Leg Room (in): 40.7
• Front Shoulder Room (in): 60.9
• Front Hip Room (in): 57.6
• Second Head Room (in): 41.1
• Second Leg Room (in): 36.8
• Second Shoulder Room (in): 64.1
• Second Hip Room (in): 60.9
• Third Head Room (in): 37.9
• Third Leg Room (in): 35.6
• Third Shoulder Room (in): 52.5
• Third Hip Room (in): 48.7
• Summary
• Vehicle Name: Ford Windstar Wagon
• Body Style: 3 Door
